| Scheda madre | Modello CPU | Intel Core i3/i5/i7 - 8°-9° gen | Intel Core i3/i5/i7/i9 11° gen | Intel Core i5/i7/i9 13° gen |
| Scheda madre | Chipset | Intel Q370 | Intel Q470E | Intel Q670E |
| Scheda madre | RAM | 4 x DDR4 2666 Mhz - 64 GB max | 4 x DDR4 2933 MHz - 128 GB max | 4 x DDR5 5600 MHz - 128 GB max |
| Scheda madre | Scheda video | Intel UHD Graphic 630 | Intel UHD Graphic 750 | Intel UHD Graphic 750 |
| Scheda madre | Watchdog timer | 1 sec.~255min SW programmable | 1 sec.~255min SW programmable | 1 sec.~255min SW programmable |
| Interfacce | LAN | 2 x GLan - Intel I219LM + I211AT | 2 x GLan Intel (I219LM + I210-AT)
+ 2 x 2,5 GLan Intel i225-LM | 2 x Intel I225-V 2.5GbE
+ 1 x Intel I225-LM 2.5GbE |
| Interfacce | Audio | Mic-in, Line-in, Line-out | Mic-in, Line-in, Line-out | Mic-in, Line-in, Line-out |
| Interfacce | Uscite video | 1 x VGA + 1 x DVI-D
+ 1 x HDMI + 1 x DP | 2 x HDMI | 1 x VGA, 1 x HDMI, 1 x DP |
| Interfacce | GPIO | Programmable on board 8-bit Digital I/O | Programmable on board 8-bit Digital I/O | Programmable on board 8-bit Digital I/O |
| Interfacce | Porte seriali | 2 x RS232 + 2 x RS232/422/485
(+ 6 x RS232 option) | 2 x RS232/422/485
(+4 x RS232 option) | 2 x RS232/422/485
(+4 x RS232 option) |
| Interfacce | USB | 4 x USB 3.1 Gen. 2 + 2 x USB 3.1 Gen. 1
(+ 2 x USB 3.1 Gen. 1 + 4 x USB 2.0 option) | 4 x USB 3.2
(+2 x USB 3.2 + 4 x USB 2.0 option) | 6 x USB 3.2
+ (+ 2 x USB 3.2 + 2 x USB 2.0 option) |
| Espansioni | 2,5” / 3,5” slots | 2 / 2 | 2 / 2 | 2 / 2 |
| Espansioni | 5,25”slots | 1 | 1 | 1 |
| Espansioni | OPTICAL DIRVE | 1 | 1 | 1 |
| Alimentazione | AC | 90~265V V - 50-60Hz | 90~265V V - 50-60Hz | 90~265V V - 50-60Hz |
| Caratteristiche generali | Protezione IP | IP40 | IP40 | IP40 |
| Caratteristiche generali | Montaggio | 19” Rack mount | 19” Rack mount | 19” Rack mount |
| Caratteristiche generali | Peso | 10 Kg | 10 Kg | 10 Kg |
| Caratteristiche generali | Temperatura lavoro | 0 - 60° C, non-condensing | 0 - 60° C, non-condensing | 0 - 60° C, non-condensing |
| Caratteristiche generali | Raffreddamento | Forzato | Forzato | Forzato |
| Caratteristiche generali | Dimensioni | 457 x 88 x 430 mm | 457 x 88 x 430 mm | 457 x 88 x 430 mm |
