CPU | Modello | Intel CoffeeLake i3/i5/i7 | Intel RocketLake i3/i5/i7 |
CPU | Frequenza base | 3,1 / 2,2 / 2,0 GHz | 3,0 / 1,3 / 1,4 GHz |
CPU | Frequenza turbo | 3,7 / 3,7 / 4,3 GHz | 3,8 / 3,7 / 4,6 GHz |
CPU | Cores | 4 / 6 / 8 | 4 / 6 / 8 |
CPU | Threads | 4 / 6 / 8 | 8 / 12 / 16 |
CPU | Cache | 6 / 8 / 12 Mb | 6 / 12 / 16 MB |
Scheda madre | RAM | Fino a 32 GB DDR4 3200 MHz SoDimm | Fino a 64 GB DDR4 2666 MHz SoDimm |
Scheda madre | Watchdog timer | Programmable by S/W - 1 sec.~255min | Programmable by S/W - 1 sec.~255min |
Unità disco | Slot m.2 | Fino a 2 TB NVMe | Fino a 2 TB NVMe |
Unità disco | Slot SATA | Fino a 2 TB SATA | Fino a 2 TB SATA |
Interfacce | LAN | 2 x GigaLan - Intel 211AT + I219LM | 1 x 2,5G Lan Intel i225LM + 1 x 1G Lan - Intel I219LM |
Interfacce | Porte seriali | 2 x RS232/422/485 | 2 x RS232/422/485 + 2 x RS232 port |
Interfacce | Uscite video | 2 x DP + 1 x HDMI | 1 x DP + 2 x HDMI |
Interfacce | USB | 4 x USB 3.1 + 2 x USB 2.0 | 4 x USB 3.2 + 2 x USB 2.0 |
Interfacce | Interfaccia GPIO | Programmable on board 8-bit Digital I/O | Programmable on board 8-bit Digital I/O |
Interfacce | Audio | Mic-in, Line-in, Line-out | Mic-in, Line-in, Line-out |
Alimentazioni | DC | 19 VDC | 19 VDC |
Caratteristiche generali | Temperatura lavoro | -20° - 50° C, non-condensed | -20° - 50° C, non-condensed |
Caratteristiche generali | Materiale scocca | Alluminio | Alluminio |
Caratteristiche generali | Montaggio | Wallmount / DIN | Wallmount / DIN |
Caratteristiche generali | Raffreddamento | Fanless | Fanless |
Caratteristiche generali | Protezione IP | IP40 | IP40 |
Caratteristiche generali | O.S. supportati | Windows 10/11, Linux | Windows 10/11, Linux |
